IC-Lora-GPS_HAT
The Lora/GPS HAT is based on the SX1276/SX1278 transceiver. The add-on L80 GPS (Base on MTK MT3339) is designed for applications that use a GPS connected via the serial ports to the Raspberry Pi such as timing applications or general applications that require GPS information.
The Lora/GPS HAT is based on the SX1276/SX1278 transceiver. The add-on L80 GPS (Base on MTK MT3339) is designed for applications that use a GPS connected_x000D_ via the serial ports to the Raspberry Pi such as timing applications or general applications that require GPS information.
_x000D_The transceivers of the Lora/GPS HAT feature the LoRa long range modem that provides ultra-long range spread spectrum communication and high interference_x000D_ immunity whilst minimising current consumption. The Lora/GPD HAT can achieve a sensitivity of over -148dBm using a low-cost crystal and bill of materials._x000D_
The high sensitivity combined with the integrated +20 dBm power amplifier yields industry leading link budget making it optimal for any application_x000D_
requiring range or robustness. LoRa also provides significant advantages in both blocking and selectivity over conventional modulation techniques,_x000D_
solving the traditional design compromise between range, interference immunity and energy consumption._x000D_
_x000D_
_x000D_
_x000D_
This board can calculate and predict orbits automatically using the ephemeris data (up to 3 days) stored in internal flash memory, so the HAT can fix position_x000D_
quickly even at indoor signal levels with low power consumption. With AlwaysLocate™ technology, the Lora/GPS HAT can adaptively adjust the on/off_x000D_
time to achieve a balance between positioning accuracy and power consumption according to the environmental and motion conditions. The GPS also supports_x000D_
automatic antenna switching function. It can achieve the switching between internal patch antenna and external active antenna. Moreover, it keeps positioning_x000D_
during the switching process.
_x000D_
Features:
_x000D_
- Frequency Band: 868 MHZ/433 MHZ/915 MHZ(Pre-configure in factory)
_x000D_
- Low power consumption
_x000D_
- Compatible with Raspberry Pi 2 Model B/Raspberry Pi 3.
_x000D_
- LoRa Modem
_x000D_
- FSK, GFSK, MSK, GMSK, LoRa™and OOK modulation
_x000D_
- Preamble detection
_x000D_
- Baud rate configurable
_x000D_
- Built-in temperature sensor and low battery indicator
_x000D_
- Excellent blocking immunity
_x000D_
- Automatic RF Sense and CAD with ultra-fast AFC
_x000D_
- Support DGPS, SBAS(WAAS/EGNOS/MSAS/GAGAN)
_x000D_
- GPS automatic switching between internal patch antenna and external active antenna
_x000D_
- PPS VS. NMEA can be used in time service
_x000D_
- Support SDK command
_x000D_
- Built-in LNA for better sensitivity
_x000D_
- EASY, advanced AGPS technology without external memory
_x000D_
- AlwaysLocate, an intelligent controller of periodic mode
_x000D_
- GPS FLP mode, about 50% power consumption of normal mode
_x000D_
- GPS support short circuit protection and antenna detection
_x000D_
LoRa specifications:
_x000D_
- 168 dB maximum link budget.
_x000D_
- +20 dBm - 100 mW constant RF output vs.
_x000D_
- +14 dBm high efficiency PA.
_x000D_
- Programmable bit rate up to 300 kbps.
_x000D_
- High sensitivity: down to -148 dBm.
_x000D_
- Bullet-proof front end: IIP3 = -12.5 dBm.
_x000D_
- Excellent blocking immunity.
_x000D_
- Low RX current of 10.3 mA, 200 nA register retention.
_x000D_
- Fully integrated synthesizer with a resolution of 61 Hz.
_x000D_
- FSK, GFSK, MSK, GMSK, LoRaTM and OOK modulation.
_x000D_
- Built-in bit synchronizer for clock recovery.
_x000D_
- Preamble detection.
_x000D_
- 127 dB Dynamic Range RSSI.
_x000D_
- Automatic RF Sense and CAD with ultra-fast AFC.
_x000D_
- Packet engine up to 256 bytes with CRC.
_x000D_
- Built-in temperature sensor and low battery indicator.
_x000D_
GPS Specifications:
_x000D_
- Power Acquisition:25mA,Power Tracking:20mA.
_x000D_
- Compliant with GPS, SBAS.
_x000D_
- Programmable bit rate up to 300 kbps.
_x000D_
- Serial Interfaces UART: Adjustable 4800~115200 bps,Default: 9600bps.
_x000D_
- Update rate:1Hz (Default), up to10Hz.
_x000D_
- Protocols: NMEA 0183, PMTK.
_x000D_
- Horizontal Position Accuracy:Autonomous <2.5 m CEP.
_x000D_
- TTFF-130dBm with EASY:Cold Start <15s,Warm Start <5s,Hot start <1s;TTFF at-130dBm.
_x000D_
- without EASY:Cold Start <35s,Warm Start <30s,Hot Start <1s.
_x000D_
- Timing Accuracy:1PPS out 10ns?Reacquisition Time <1s.
_x000D_
- Velocity Accuracy Without aid <0.1m/s,Acceleration Accuracy Without aid 0.1m/s?.
_x000D_
- Sensitivity Acquisition -148dBm?Tracking -165dBm?Reacquisition -160dBm.
_x000D_
- Dynamic Performance Altitude Max.18000m?Maximum Velocity Max.515m/s?Maximum Acceleration 4G.
_x000D_
- L1 Band Receiver(1575.42MHz) Channel 22 (Tracking) /66 (Acquisition).
_x000D_
Includes:
_x000D_
- 1x Lora/GPS HAT
_x000D_
- 4x Brass cylinders
_x000D_
- 4x Screws
_x000D_
- 4x Nuts
_x000D_
- 1x Glue Stick Antenna(868 MHZ, 433 MHZ or 915 MHZ depends on order)
_x000D_
Warranty_x000D_
- 1 Year Manufacturer Warranty + Additional 1 Year Instrument Choice Warranty_x000D_
