Conductivity/TDS/NaCl/Temperature Laboratory Bench Meter - IC-MW170-MAX

ORDER ME IN
Product code: IC-MW170-MAX

Order Me In, once ordered this item will likely dispatch before the 30th of August 2025, call 1300 737 871 (NZ 0800 737 871) to confirm.

The MW170 MAX is a compact and versatile bench meter that can measure up to four different parameters: EC, TDS, salinity (in PSU, g/L, percentage NaCl) and temperature. The main operating modes are setup, calibration, measurement and logging.

Regular price $1,773.90 AUD + GST
$1,951.29 AUD Inc. GST
The MW170 MAX is a compact and versatile bench meter that can measure up to four different parameters: EC, TDS, salinity (in PSU, g/L, percentage NaCl) and temperature. The main operating modes are setup, calibration, measurement and logging.
Features
- Easy to read LCD display
- Auto-off feature to prolong battery life
- All measurements can be temperature compensated automatically (ATC), or manually (MTC) with a user-selectable compensation coefficient.
- Temperature compensation can be disabled (NO TC) if the actual conductivity value is required.
- The auto-ranging feature for both EC and TDS measurements automatically sets the most suitable resolution for the tested sample.
- Available log space for up to 1000 records. Logged data can be exported using a USB cable.
- Dedicated GLP key to store and recall data on system status
- Built-in rechargeable battery with 8 hours battery life
Ordering information
- MA814D/1 EC/Temperature probe
- MA9315 Electrode Holder
- Micro USB cable
- 12 VDC Adapter
- Instruction Manual

Specifications

Range
Resolution
Accuracy
EC: 0.00 o 29.99 uS/cm; 30.0 to 299.9 uS/cm; 300.0 to 2999 uS/cm; 3.00 to 29.99 mS/cm; 30.0 to 200.0 mS/cm; up to 500 mS/cm absolute conductivity
TD: 0.00 to 14.99 mg/L (ppm); 15.0 to 149.9 mg/L (ppm); 150 to 1499 mg/L (ppm); 1.5 to 14.99 g/L (ppt); 15.0 to 100.0 g/L (ppt); up to 400 g/L absolute TDS
Salinity: 0.00 to 400.0 % NaCl; 2 to 42 PSU; 0.00 to 80.00 g/L
Temperature: -20 to 120 C/ -4 to 248 F
EC: 0.01 uS/cm; 0.1 uS/cm; 1.0 uS/cm; 0.01 mS/cm; 0.1 mS/cm
TDS: 0.01 mg/L; 0.1 mg/L; 1.0 mg/L; 0.01 g/L; 0.1 g/L
Salinity:0.1 % NaCl; 0.01 PSU; 0.01 g/L
Temperature: 0.1 C/F
EC: +/1 % of reading (+/- 0.05 uS/cm or 1 digit, whichever is greater
TDS: +/1 mg/L % of reading (+/- 0.05 uS/cm or 1 digit, whichever is greater
Salinity: +/1 %
Temperature: +/0.5 C/ +/- 0.9 F
- Temperature Compensation: Automatic, -5.0 to 100.0C (23 to 212 F), manual, -5.0 to 100.0C, and no temperature compensation
- pH electrode: MA917B/1 glass, double junction pH electrode (supplied)
- Temperature coefficient: 0 to 6% C (EC and TDS only)
- Probe: MA814DB1 4-ring probe with built-in temperature sensor (included)
- TDS Factor: 0.40 to 0.80
- Log: Maximum of 1000 records; On demand, 200 max; On stability, 200 max samples; Interval logging, 1000 samples max
- PC connectivity: 1 micro USB port
- Power supply: 12VDC (included)
- Battery life: Approx. 8 hours of use
- Environment: 0 to 50C / 32 to 122F; max RH 95%
- Weight: 2.16 kg / (2.0 lbs)
Warranty
- 1 Year Manufacturer Warranty + Additional 1 Year Instrument Choice Warranty for the bench meter. 6 months warranty for the probe
