ZTAG-EU Single-use Temperature Data Logger
Order Me In, Once ordered this item will likely dispatch before the 29th of March 2026, call 1300 737 871 (NZ 0800 737 871) to confirm.
The ZTAG-EU is a single-use temperature data logger that monitors the temperature of products and shipments during transit. It functions as a cost-effective record label and uses food-grade composite bags,...
$17.60 AUD Inc. GST
The ZTAG-EU is a single-use temperature data logger that monitors the temperature of products and shipments during transit. It functions as a cost-effective record label and uses food-grade composite bags, which are completely waterproof. After one-click activation, it can be placed in the target monitoring environment to monitor and record the temperature of fresh food, medicine and other products during storage and transportation.
The ZTAG-EU is ideal for long-haul shipments and easy integration into logistics workflows. It can be used in all aspects of storage and logistics cold chain, such as refrigerated containers, refrigerated trucks, refrigerated bags, cold storage, laboratories, etc.
After the trip is completed, plug the recorder into your computer to read the report. The report cannot be tampered with, and the authoritative report can trace the temperature data of the entire trip.
Features
- Wide measuring range and accuracy: -30 to 70°C with built-in high-precision NTC sensor
- High capacity: Stores 33,000 data points
- Drive-free encryption report: easily generates a report of the temperature logs during transit
- Food grade composite bag: Uses food-grade fully sealed composite bags with IP67 protection level
- One-click start, simple and easy to use: Parameters are pre-configured before leaving the factory, and trip data can be recorded with one click. It is simple and easy to use
- Air Freight Compliance: Complies with RTCA/DO-160G environmental conditions and test procedures for airborne equipment, qualified for air shipment in active status
Specifications
- LED indicator: Green（Recording，OK），Red（Alarm），Yellow（Start Delay）
- Battery life: Up to 2 years(1 year storage / 1 year useful life)@25℃，5 minutes logging interval
- Measurement range: -30 to 70°C
- Measurement accuracy: ± 0.5°C @-10~40 C, ± 0.8°C @-30 ~-10°C & 40~70°C
- Resolution: 0.1°C
- Alarm point: can set high and low 2 alarm points (alarm threshold and over-temperature trigger time can be customized according to customer needs)
- Recording interval: 1 minute -24 hours (can be factory configuration) default 10 minutes
- Storage capacity: Up to 33,000 points@Single PDF/CSV report，25,000 Points @PDF&CSV report
- Startup delay: 0 minutes -24 hours (can be configured before factory) default 15 minutes
- Start Mode: Manual Start
- Report Format: PDF/CSV/PDF & CSV (optional, factory configured)
- Battery Type: 3.0V CR2450
- Connection Mode: USB2.0
- Product Size: 70 x 34 x 7mm
- Product Weight: 23g
- Certification: CE,EN12830:2018,RTCA/DO-160G (Aviation Safety Directive),RoHS
