TM-604N Three-Phase Motor Rotation Tester - IC-TM-604N
Backorder Now, once ordered your item will dispatch before the 27th of June 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).
Three-Phase motor rotation tester for phase sequence testing and checking motors for rotation direction. Can also be used to identify phase sequence of three phase electrical systems or to identify normal or reversed phases as well as loss of phase.
- Precision instrument built for indoor use.
- Complies with UL61010-1,and CSA C22.2 No.61010-1 (between ground and input terminal) and EN 61010-1(2001) and EN61557.
Regular price
$209.30 AUD
+ GST
$230.23 AUD Inc. GST
$230.23 AUD Inc. GST



Note: For indoor use only. Do not put this device in direct sunlight or where it is hot and/or damp.
Three-Phase motor rotation tester for phase sequence testing and checking motors for rotation direction. Can also be used to identify phase sequence of three phase electrical systems or to identify normal or reversed phases as well as loss of phase.
Safety and maintenance standards The instrument complies with : UL61010-1,and CSA C22.2 No.61010-1 (between ground and input terminal) and EN 61010-1(2001) and EN61557.
2 Year Warranty (1 Year Manufacturer Warranty + Bonus 1 Year Instrument Choice Warranty)
TM-604N Features
- Display by LED indicators
- Inter-phase voltage: 45V AC up to 600V AC
- Signal Frequency Range: 45Hz to 400Hz
- Test Currents inter-phase less than 3.5mA
- Two UL 500mA/700V fuse protection
- Low battery detection
Standard package includes:
TM-604N meter, 3 crocodile clips, test leads (3pcs.) and user's manual
Specifications
Type of tester:
|
Phase sequence
|
Display:
|
LED
|
Phase-to-phase voltage range for phase sequence indication:
|
45 to 600V AC
|
Operating frequency:
|
45 to 400Hz
|
Body dimensions:
|
143 x 68 x 35mm
|
Weight with battery:
|
150g
|
Conform to the norm:
|
CAT III 1000V, CAT IV 600V, EN 61010
|
Measurement:
|
Motor's rotation direction, phase sequence
|
