Features:
- 4.3" color LCD touch screen display provides an intuitive interface
- Rapid heating, cooling and high speed shaking ability
- Internal memory stores five separate 5-step programs, unlimited with USB
- Low Profile Design: The low profile design minimizes the unit?s footprint on the bench.
- LCD Touch Screen: Enables faster setting of temperature, speed, and time which can all be viewed at once. Display features on-screen help topics with
operational tips available in six languages. Touch screen is compatible with rubber gloves used in labs. USB port can transfer information to a flash
drive for data logging, program storage and software updates.
- Program Control: Program control capabilities allow user programmable operation for automated use and memory. Storage for five separate 5-step programs,
or unlimited number of programs with the use of the USB.
- Temperature ramp rate: Adjustable temperature ramp rate feature separately defines the heating and cooling rate in increments of 0.5 C/min.
- Single Point Calibration Mode: For maximum temperature accuracy, the single point calibration procedure allows the user to calibrate up to 6 different
user defined temperatures.
- Pulse Mode Feature: The unit is equipped with a pulse mode feature for quick vortex applications.
Safety Features:
- Cool Touch Housing: Constructed from a high-quality, heat and chemical resistant polymer. The unit?s housing remains cool to the touch throughout normal
operating temperatures.
- Maximum Temperature Limiting Function: Ensures the temperature will not exceed preset limits, allowing the user control of temperature sensitive samples.
- Hot Top Indicator: A hot top warning light will illuminate when the temperature reaches 40 C, and will remain lit until the unit is sufficiently cooled.
- Audible Alarm: In timed mode, an alarm will sound when the time reaches zero or set-point temperature is reached. Additionally, the heat function will
automatically shut off if the unit recognizes an internal issue.
Operating Conditions:
Unit can operate in conditions from 5 to 35 C (41 to 95 F), maximum 80% relative humidity, non-condensing.
Specifications
- Temperature Range: 4?C above ambient to 100?C
- Temperature Accuracy: +- 1 C between 20 C and 45 C +-0 2 C above 45 C
- Speed Range: 300 to 3000 rpm
- Speed Accuracy: +- 2%
- Timer: 1 minute to 99 hours, 59 minutes
- Orbit: 3 mm (0.12")
- Cooling Rate (above ambient): 2-3 C/min
- Cooling Rate (below ambient): 0.5-1.0 C/min
- Heating Rate: 5 C/min
- Overall Dimensions (L x W x H): 10.25 x 9.75 x 5.2" (26 x 24.8 x 13.2 cm)
- Ship Weight: 11.9 lbs (5.4 kg)
