Testo 477 LED stroboscope

ORDER ME IN
Product code: 0563-4770

Backorder Now, once ordered your item will dispatch before the 12th of June 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).

The testo 477 LED stroboscope makes stunningly fast movements look as if they are taking place in slow motion. This allows you to check and inspect machines and systems while they are still running, and measure speeds of up to 300 000 rpm.

-Extremely high measurement range: up to 300 000 flashes per minute (fpm).

-Very high illumination: up to 4800 Lux.

-Long operating times: battery power for up to 5 h.

-Trigger input and output for connectivity to external systems and control via external sensor.

Read more

$1,709.00 AUD + GST
 $1,879.90 AUD Inc. GST
The testo 477 LED stroboscope makes stunningly fast movements look as if they are taking place in slow motion. This allows you to check and inspect machines and systems while they are still running, and measure speeds of up to 300000 rpm.
It is impossible to tell with the naked eye if the thread guide of a knitting machine is working properly. It therefore equally impossible to tell if there are any irregularities in vibration or rotational processes of machines or systems. But its a different story with the testo 477 LED stroboscope. Thats because the stroboscope emits a series of flashes which makes what you see appear as a frozen image.
The testo 477 LED stroboscope can also measure the rotational speed of very small and hard-to-reach objects. And because theres no need for reflex marks, theres no need to stop the machines and no disruption to production processes either.
An extremely high measurement range of up to 300000 flashes per minute (fpm) and a very high illumination of up to 1500 Lux allow you to carry out rotational speed measurements of up to 300000 rpm. A trigger input and output ensure connectivity to external systems and control via an external sensor.
The LED stroboscopes integrated impact protection and sturdy IP65 rated housing (which also allows it to be wiped down) ensure that the testo 477 can stand up to the rough and tumble of everyday use. And thanks to a longer battery operating time, you can carry out uninterrupted measurements for up to 5 hours.

Specifications

- Measuring range: 30 to 300000 fpm
- Accuracy: 0.02 % of mv
- Resolution: +/- 0.1 (30 to 999 fpm); +/- 1 (1000 to 300000 fpm)
- Protection class: IP65
- Flash duration: Can be adjusted
- Flash intensity: 4800 Lux at 6000 FPM / 30 cm
- Flash colour: Approx. 6500 K
- Battery life: NiMH rechargeable battery: Approx. 11 h at 6000 fpm; Batteries: approx. 5 h at 6000 fpm (3 x AA)
- Display type: LCD (Liquid Crystal Display)
- Display size: multiline
- Reverse battery protection: yes
- Low level: less than 1 V
- Maximum current: 50 mA
