PCE-VDL 16I Vibration Analyzer

ORDER ME IN
Product code: PCE-VDL-16I

Backorder Now, once ordered your item will dispatch before the 13th of August 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).

The PCE-VDL 16I is a multifunction vibration and shock logger that also measures temperature, humidity, light and air pressure.

-3-axis Acceleration up to 800 Hz.

-Small and compact, perfect for machine monitoring for shock and vibration and fault diagnosis.

-Includes 32 GB SD card.

Read more

$779.10 AUD + GST
 $857.01 AUD Inc. GST
The vibration analyzers of the PCE-VDL series are available in two versions. The vibration analyzer PCE-VDL 16I contains sensors for the following physical units: temperature, humidity, air pressure, light and 3-axis acceleration. The max. sampling rate of the acceleration sensor is 800 Hz, the remaining sensors are sampled with max. 1 Hz.
Shock and vibration logger is therefore ideally suited for use in fault diagnosis, stress testing, machine inspection, shock measurements and preventive maintenance.
Features:
- 3-axis Acceleration up to 800 Hz
- For temperature, humidity, air pressure and light
- 32 GB SD memory card
- Small design: 86.8 x 44.1 x 22.2 mm
- Made in Germany

Specifications

3 Axes Acceleration:
- Measuring range: +/- 16 g
- Accuracy: 0.24 g
- Resolution: 0.00390625 g
- Max. Sampling rate: 800 Hz
Temperature:
- Measuring range: -20 to 65 C
- Accuracy: +/- 0.2 C
- Resolution: 0.01 C
- Max. Sampling rate: 1 Hz
Humidity:
- Measuring range: 0 to 100%RH
- Accuracy: +/- 1.8%RH
- Resolution: 0.04%RH
- Max. Sampling rate: 1 Hz
Air pressure:
- Measuring range: 10 to 2000 mbar
- Accuracy: +/- 2 mbar (750 to 1100 mbar); otherwise +/- 4 mbar
- Resolution: 0.02 mbar
- Max. Sampling rate: 1 Hz
Light:
- Measuring range: 0.045 to 188,000 Lux
- Resolution: 0.045 Lux
- Max. Sampling rate: 1 Hz
