Kyoritsu 3005A Digital Insulation and Continuity Tester

ORDER ME IN
Product code: 3005A

Order Me In, once ordered this item will likely dispatch before the 02nd of August 2025, call 1300 737 871 (NZ 0800 737 871) to confirm.

The Kyoritsu 3005A is a microprocessor controlled digital insulation/continuity tester that not only measures insulation resistance on three rated test voltages (250V, 500V and 1,000V) and continuity testing, but also offer a number of convenient features such as a bargraph reading of insulation resistance or auto null function for continuity testing.

Regular price $1,370.00 AUD + GST
$1,507.00 AUD Inc. GST
The Kyoritsu 3005A is a microprocessor controlled digital insulation/continuity tester that not only measures insulation resistance on three rated test voltages (250V, 500V and 1,000V) and continuity testing, but also offer a number of convenient features such as a bargraph reading of insulation resistance or auto null function for continuity testing.
Features:
- Bargraph to display insulation resistance.
- Displays the value of external AC voltage along with flashing symbol.
- Auto null function to automatically subtract the test lead resistance before displaying the real continuity resistance value.
- Live circuit warning beeper.
- Releasing the test button automatically discharges the charges stored in the circuit under test.
- 200mA continuity measuring current to IEC 61557.
- Minimum 1mA current on insulation tests to IEC 61557.

Specifications

Insulation Resistance:
- Test voltage: 250V/500V/1000V
- Measuring ranges (Mid-scale value): 20 milliohms/200 milliohms/2000 milliohms
- Output voltage on open circuit: Rated test voltage + 20%, -0%
- Nominal current: 1mA DC min.
- Output short circuit current: 1.5 mA DC approx.
- Accuracy: +/- 1.5%rdg +/- 5dgt (20 milliohms/200 milliohms) +/- 10%rdg +/- 3dgt (2000 milliohms)
Continuity Test:
- Measuring ranges (Mid-scale value): 20 ohms/200 ohms/2000 ohms
- Output voltage on open circuit: 7 - 12V DC
- Measuring current: 200mA DC min.
- Accuracy: +/- 1.5%rdg +/- 5dgt (20 ohms) +/- 1.5%rdg +/- 3dgt (200 ohms/2000 ohms)
AC Voltage:
- AC voltage range: 0 - 600V AC
- Accuracy: +/- 5%rdg +/- 3dgt
General:
- Safety Standard: IEC 61010-1 CAT III 300V Pollution Degree 2, IEC 61010-2-031 IEC 61557-1/2/4, IP Rating IEC 60529-IP54
- EMC Standard: IEC 61326-1
- Power source: R6 (AA) (1.5V) x 8
- Dimensions: 167(L) x 185(W) x 89(D)mm
- Weight: 970g approx
