HM110-PND Humidity Transmitter
Order Me In, once ordered this item will likely dispatch before the 10th of September 2025, call 1300 737 871 (NZ 0800 737 871) to confirm.
The HM110 is a humidity transmitter with a measurement range from 5 to 95%RH. This model has a duct probe with no display and passive 16/30 Vdc – 4-20 mA power.
$384.01 AUD Inc. GST
Specifications
Measuring range
|
from 5 to 95% RH
|
Accuracy
|
2% RH (if 15C T 25C) on ambient model
|
Response time
|
4s
|
Resolution
|
0.1% RH
|
Drift linked to temperature
|
0.04 x (T-20) %RH (if 15C T 25C)
|
Type of sensor
|
Capacitive
|
Resolution
|
0.1% RH
|
Factory adjustment uncertainty
|
0.88% RH
|
Type of fluid
|
Air and neutral gases
|
Display:
|
LCD 10 digits. Size: 50 x 17 mm
|
Height of digits:
|
Value: 10 mm ; Unit: 5 mm
|
Cable gland:
|
for cables 8 mm maximum
|
Cable of remote probes:
|
length 2 m and 4.8 mm in silicone
|
