Waterproof Free Chlorine and Total Chlorine Colorimeter Kit Set with reagents and carrying case - EC-C201
Unfortunately, the EC-C201 has been discontinued, check out our other Colorimeters for more options.
This item has been discontinued, please call 1300 737 871 (NZ 0800 737 871) for an alternative.
Product Features
Excellent repeatability, auto-ranging and easy to use
The meter ensures excellent repeatability, has auto-ranging capabilities while using only one-vial-one-sachet per test.
High Quality Reagents
The custom-formulated reagents provide excellent accuracy, repeatability and stability. They are conveniently packed for ease of use.
USEPA-approved DPD method*
Chlorine measurements are based on the USEPA-approved DPD method*.
Advanced Power Management
The meter is capable of measuring more than 3,000 tests using a single set of 4 AAA alkaline batteries. Auto power-off activates after 10 minutes of non-use to conserve battery life.
Fuss-free Meter Operation
The meter is designed for easy operation. It allows one-time blanking for all parameters and ranges when measuring the same sample. The blanking value is stored in memory even if batteries are replaced. Furthermore, no calibration is needed for Chlorine and Cyanuric Acid. Most importantly, the meter is maintenance-free.
Large Easy-to-read Display
The large screen features 4-digit 14-segment customized liquid crystal display (LCD) with mode indicators to guide meter use.
IP67 waterproof and lightweight
The lightweight meter has a waterproof IP67-rated housing. It even floats when accidentally dropped in water.
Specifications
Product Specification |
Description | ||||||||||
| Parameters | Range | Resolution | Accuracy | C401 | C301 | C201 | C105 | C104 | C103 | C102 | C101 |
| Chlorine, Free and Total | 0 to 1.99 ppm | 0.01 ppm | 0.02 ppm | ||||||||
| 2.0 to 6.0 ppm | 0.1 ppm | 0.2 ppm | |||||||||
| Cyanuric Acid | 5 to 90 ppm | 1 ppm | 4 ppm | ||||||||
| pH | 5.9 to 8.2 pH | 0.1 pH | 0.1 pH | ||||||||
| Chlorine Dioxide | 0 to 3.79 ppm | 0.01 ppm | 0.02 ppm | ||||||||
| 3.8 to 11.4 ppm | 0.1 ppm | 0.2 ppm | |||||||||
| Bromine | 0 to 4.49 ppm | 0.02 ppm | 0.03 ppm | ||||||||
| 4.5 to 13.5 ppm | 0.2 ppm | 0.3 ppm | |||||||||
| Ozone | 0 to 1.39 ppm | 0.01 ppm | 0.02 ppm | ||||||||
| 1.4 to 4.1 ppm | 0.1 ppm | 0.2 ppm | |||||||||
| Measurement Method | Photometric | ||||||||||
| Light Source | Light Emitting Diode (LED) | ||||||||||
| Wavelength | 525nm | ||||||||||
| Detector | Silicon photodiode | ||||||||||
| Absorbance Range | 0 - 2.5 Abs | ||||||||||
| Photometric Precision | 0.0015Abs | ||||||||||
| Automatic Range Selection | 0 - 1.99 ppm (Free & Total Chlorine)
2.0 - 6.0 ppm (Free & Total Chlorine) 5 - 90 ppm (Cyanuric Acid) 5.9 - 8.2 pH |
||||||||||
| Resolution | 0.01 ppm (0 - 1.99 ppm; Free & Total Chlorine)
|
||||||||||
| Accuracy | 0.02 ppm (0 1.99 ppm; Free & Total Chlorine)
0.2 ppm (2.0 6.0 ppm; Free & Total Chlorine) 0.1 pH (5.9 8.2 pH) 4 ppm; Cyanuric Acid |
||||||||||
| Calibration Points | User selectable; 1 point per colorimetric test | ||||||||||
| Display | 4-digit 14-segments customized liquid crystal display with annunciators | ||||||||||
| Sample Cells | Borosilicate glass with screw caps, fill line and indexing mark Height x Diameter : 51 x 25 mm | ||||||||||
| Sample Volume Required | 10 ml | ||||||||||
| Operating Temperature Range | 0 50C | ||||||||||
| Operating Humidity Range | 0-90% RH non-condensing at 30C | ||||||||||
| Power Supply | 4 AAA alkaline batteries | ||||||||||
| Battery Life | > 3000 tests | ||||||||||
| Electromagnetic | EN 61326 Compliance (EMC) | ||||||||||
| Weight Instrument : | 200g | ||||||||||
| Complete carrying case : | 1.25kg | ||||||||||
| Dimensions Instrument : |
6.8(W) x 15.5(L) x 4.6(H) cm | ||||||||||
| Carrying case : | 16(W) x 35(L) x 12(H) cm | ||||||||||
