Backorder Now, once ordered your item will dispatch before the 15th of June 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).
$6,038.56 AUD Inc. GST
Features:
- Sound Analysis at predetermined frequencies using 1/1 octave filter
- Range 95dB
- Frequency 1Hz to 20 kHz
- Microphone type 1 re-Polarised 0.5 (50mV / Pa)
- Measuring parameters: LSPL, LEQ, LMAX, LMIN, Peak, LEPd, Exposure Points, Dose, Hearing Protector Calculator 1/1
Octaves
- Works with 4 AA batteries.
- Accompanied by 1/1 octave filter and USB cable
Specifications
- dBAir Safety Octave: LSPL, LEQ, LMAX, LMIN, Peak, LEPd, Exposure Points, Dose, Hearing Protector Calculator. 1/1 Octaves:
- Applicable Standards: IEC 61672-1:2013 IEC 61260-1:2014 (Where Octave Bands Fitted) IEC 61252:1993 amendment 1:2000
(Where Exposure Fitted)
- Microphone: Class 1:Type 1 Pre-Polarised (50mV/Pa) Condenser Microphone -26 dB +/- 2 dB re 1V/Pa Class 2:Type 2
Pre-Polarised (25mV/Pa) Condenser Microphone 32 dB +/- 3 dB re 1V/Pa
- Measurement Ranges: Linear Operating Range: 95dB
- Noise Floor: Typical "A" Weighting Frequency; Weightings Measurement 1: A, C or Z Measurement 2: A, C or Z
- Frequency Range: 1 Hz to 20 kHz (electrical characteristics) Class 1: 12.5 Hz - 20 kHz (including microphone) Class
2: 16Hz - 16kHz (including microphone)
- Time Weighting: Measurement 1: Slow, Fast, Impulse Measurement 2: Slow, Fast, Impulse
- Display: 2.4" Full Colour TFT 240x320 pixels
- Dual Measurements: Simultaneous dual measurement with independent time and frequency weightings
- Octave Band Analysis: Where fitted 1/1 or 1/3 octave band analysis on measurement 1 only
- Time History: Short Interval: 10ms to 60m Long Interval: 1s to 24h Smart Timer, Duration Timer or Interval Timer
- Memory: 16GB, 32GB, 64GB Input / Output Connection Micro USB Type B
