CTV110-VND150 Air Velocity and Temperature Transmitter (Remote)

ORDER ME IN
Product code: CTV110-VND150

Order Me In, once ordered this item will likely dispatch before the 17th of September 2025, call 1300 737 871 (NZ 0800 737 871) to confirm.

Kimo CTV110-VND150 remote air velocity and temperature transmitter designed for air velocity and temperature measurement and control.

  • Measuring range from 0 to 30 m/s and from and from 0 to 50 C.
  • 0-10 V or 4-20 mA output, active, power supply 24 Vac/Vdc (3-4 wires) and 150 meter cable.
  • Built using ABS V0 housing, with IP65 protection without display.

Read more | Need help? 3 Hour Business Reply

$509.60 AUD + GST
 $560.56 AUD Inc. GST
Kimo CTV110-VND150 remote air velocity and temperature transmitter designed for air velocity and temperature measurement and control.
Features:
- Measuring range from 0 to 30 m/s and and from 0 to 50 C
- Remote model, 0-10 V or 4-20 mA output, active, power supply 24 Vac/Vdc (3-4 wires)
- Alternating display of air velocity and temperature
- 1/4 turn system mounting with wall-mount plate
- Housing with simplified mounting system

Specifications

- Measuring ranges (Air temperature): From 0 to 50 C
- Measuring ranges (Air Velocity): 0 to 30 m/s
- Accuracy: +/- 0.3% of reading; +/- 0.25 C
- Accuracy from 0 to 3 m/s: +/- 3% of reading +/- 0.05 m/s
- Accuracy from From 3 to 30 m/s: +/-3% of reading +/- 0.2 m/s
- Unit of measurement: C, F m/s and fpm
- Response time: 1/e (63%) 5 s 1/e (63%) 2 s
- Type of sensor: Pt100 1/3 DIN Hotwire
- Resolution: 0.1 C From 0 to 3 m/s: 0.01 m/s
- Resolution: From 3 to 30 m/s: 0.1 m/s
- Type of fluid Air and neutral gases Filtered air
- Output / Power supply: Active sensor 0-10 V, 3-4 wires
- Maximum load: 500 ohms (4-20 mA) / minimum load: 1 kiloohms (0-10 V); Consumption 3 VA
- European directives: 2014/30/EU EMC; 2014/35/EU Low Voltage; 2011/65/EU RoHS II; 2012/19/EU WEEE
Electrical connection Screw terminal block for cables from 0.05 to 2.5 mm2 or from 30 to 14 AWG
