- 5 lb capacity
- Large 14 x 11" Tray
- Variable control for speed, tilt and time
- Low Profile Design: Takes up less space and easily fits into most hoods and incubators. Cast aluminum base offers durability and added stability.
- Microprocessor Control: Provides tilt adjustment which allows user to easily adjust waving angle from 0 to 16? while unit is operating. Smooth speed
control with low speed waving motion.
- Independent Control Knobs: Independent control knobs for speed, tilt and time allow for easy adjustments.
Safety Features:
- Overload Protection: Audible and visual signals will activate when system detects an obstruction or overload of the tray.
- Speed Ramping Feature: Slowly increases speed to desired set-point to avoid splashing.
- Timer: Timer, if engaged, will automatically stop waving motion when timer reaches zero.
- Spill-Resistant Design: Channels fluids away from internal components.
Operating Conditions:
Unit can be run in cold rooms, incubators, and environments from -10 to 60 C (14 to 140 F), maximum 80% relative humidity, non-condensing.
Applications:
Staining and destaining gels, hybridization procedures, hematology, and blotting techniques.
Specifications
- Speed Range: 1 to 75 rpm (Maximum speed/tilt angle may vary with heavy or unbalanced loads)
- Tilt Angle: 0 to a 16 degree angle (Maximum speed/tilt angle may vary with heavy or unbalanced loads)
- Timer: 1 minute to 120 minutes
- Maximum Weight Capacity: 5 lbs (2.3 kg), centered on tray
- Tray Material: Aluminum
- Tray Dimensions (L ? W): 14 x 11" (35.6 x 27.9 cm)
- Overall Dimensions (L x W x H): 16.8 x 11 x 6.5" (42.5 x 27.9 x 16.5 cm)
- Ship Weight: 15.5 lbs (7 kg)
