200mVdc full scale, Annunciators, Bezel Mounted, Panel Meter - IC-DPM 600
Backorder Now, once ordered your item will dispatch before the 22nd of May 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).
The DPM 600 is a 3 and a half digit LCD voltmeter with 12.5mm (0.5") digit height. It features 200mV d.c. full scale reading, bandgap reference,auto-zero, auto-polarity and a set of annunciators. The meter can be panel mounted using the bezel and window. Connection to the meter is via solder pads.
Regular price
$94.00 AUD
+ GST
$103.40 AUD Inc. GST
$103.40 AUD Inc. GST
Features:
3 Digit LCD Voltmeter
200mV Full Scale Reading
Auto-zero, Auto-polarity
Bandgap Reference
Bezel Mounted
Accuracy (overall error): 0.05 to 0.1 % (1 count)
Linearity: 1count
Sample rate: 3 samples/sec
Operating temperature range: 0 to 50 C
Temperature stability: 30 ppm/C
Supply voltage: 5 to 9 V d.c.
Supply current: 150 uA
Input leakage current: 1-10 pA
Specifications
Accuracy (overall error): 0.05 to 0.1 % (1 count)
Linearity: 1count
Sample rate: 3 samples/sec
Operating temperature range: 0 to 50 C
Temperature stability: 30 ppm/C
Supply voltage: 5 to 9 V d.c.
Supply current: 150 uA
Input leakage current: 1-10 pA
