A standard ceramic reference junction in a soil pH tester's electrode can quickly become clogged when measuring samples with high suspended solids concentrations. The IC-HI981030 Groline Soil pH Tester features an open reference junction with a removable sleeve design to counteract this potential problem.
While the Groline Soil pH Tester's unique open gel interface between the sample and internal reference minimises the risk of junction blockage, if any soil enters the junction, it can easily be cleaned and refreshed using more bridge electrolyte solution.
This quick video guide details replacing and filling the electrolyte solution in a Groline Soil pH Tester.
Figure 1 Watch here to see an Instrument Choice Scientist demonstrate how to refill the Groline Soil PH Tester (IC-HI981030) with an electrolyte solution.
How to Refill the Electrolyte Solution in the Groline Soil PH Tester (IC-HI981030)
Materials Required
- The GroLine Soil pH Tester - IC-HI981030
- Electrode cleaning solution(included with IC-HI981030)
- Electrode storage solution (included with IC-HI981030)
- Gelled Bridge Electrolyte (included with IC-HI981030); and
- Purified water. We used Deionized Water.
How to Refill the Electrolyte Solution in the Groline Soil PH Tester
- Remove the electrode storage cap.
- Remove the sleeve. Carefully rotate the sleeve to loosen the seal, then pull it straight along the electrode to remove it altogether. Use extreme care as the pH stem is glass.
- Rinse off any traces of the old electrolyte gel in the water.
- Soak the sensor tip in the cleaning solution for 20 minutes.
- After 20 minutes has elapsed, rinse with purified water.
-
Refill the reference well with the gelled bridge electrolyte (Figure 1 below).
Figure 1 Reference well on the IC-HI981030 Groline Soil pH Tester
- When filled, replace the reference sleeve. Insert and push the sleeve onto the electrode. Make sure the black o-ring is secure inside the electrode body. Any excess gel will be expelled from the end of the electrode.
- Rinse any excess gel off with purified water and gently shake dry.
- Carefully shake the electrode down as you would with a clinical thermometer to eliminate any air bubbles inside the glass bulb.
- Soak the reassembled probe in electrode storage solution for a minimum of 30 minutes.
- Electrolyte replacement is complete! Rinse and calibrate before use.
Conclusion
Replacing the electrolyte solution in the IC-HI981030 is necessary whenever the solution becomes dirty, and it's a great way to troubleshoot any unusual measurements.
